Intended Use：
- D65 Standard Illuminant: Utilizes Artificial Daylight D65, recognized by the International Commission on Illumination (CIE), as the primary standard light source. The illuminance range is 750 to 3200 Lux. The interior background is finished in a neutral grey, with a reflectance rate of less than one-third of the incident light.
- UV Source: Provides an Ultra-Violet (UV) light source for detecting fluorescent substances and optical brightening agents in materials.
- Store Light Sources: Includes retail/store illuminants for cross-source color comparison. It is suitable for 24/7 applications in printing, paint, ink, plastics, dyeing, and any industry requiring precise color observation and color matching.
Operating Principle：
Microcomputer Control: Utilizes microcomputer-controlled instant switching between various light sources. This eliminates the flickering associated with domestic fluorescent tubes, ensuring an accurate comparison of color differences under different lighting conditions.
Lifetime Tracking: Accurately records the usage time of each lamp group. Generally, lamps should be replaced after 2,000 hours of use to prevent measurement errors caused by spectral shifting due to aging.
Product Features
Product Features：
- Metamerism Detection: Capable of detecting the Metamerism Effect (where colors match under one light source but not another).
- Rapid Assessment: No preheating required; flicker-free operation ensures fast and reliable color evaluation.
- High Efficiency: Features low power consumption, minimal heat generation (no cooling required), and high luminous efficiency.
- Compact & User-friendly: Compact footprint and easy to operate.
Standards：
D65 International Standard Artificial Daylight, Color Temp: 6500K, Power: 18W; TL84 Euro/Japan/China Store Light, Color Temp: 4000K, Power: 18W; F Family/Hotel Light, Color Ref Source, Color Temp: 2700K, Power: 40W; UV Light Source (Ultra-Violet), Wavelength: 365nm, Power: 20W
Application Fields：
Packaging | Food | Pharmaceuticals | New Materials | Chemical Industry | Printing
Technical Parameters：
Light Source Configuration
D65、TL84、F、UV
External Dimensions
710mm*405mm*570mm
Internal Dimensions
680mm*380mm*390mm
Standard Configuration：
Mainframe, Other Accessories
